30kg Rail
Product Overview
Gloryrail presents the 30kg/m light rail, rigorously engineered to meet GB/T 11264-2012 Hot-Rolled Light Rails, offering superior performance for industrial. With a theoretical weight of 30.1kg/m and customizable lengths (6–24 meters), it excels in medium/heavy-load environments such as mine main haulage roads, port container crane tracks, metallurgical zone.
Key Features
GB Standard Compliance & Precision Engineering
Dimensional Accuracy:
Rail height: 107.95mm (±0.5mm); base width: 107.95mm (±0.5mm)
Web thickness: 12.3mm (±0.5mm); length tolerance: ±6mm
Bolt hole positioning error ≤0.3mm, burr height ≤2mm for seamless integration with standard accessories (fishplates, fasteners).
Surface Quality: Defect-free hot-rolled surface with allowable web scratches ≤0.75mm deep, ensuring rapid on-site installation and compliance with international transport standards.
Material Performance
Q235B Carbon Steel (Standard)
Tensile strength: 375–460MPa; yield strength ≥235MPa
Cost-effective with excellent weldability for on-site modifications and extensions.
55Q Special Steel (Custom Option)
Tensile strength ≥685MPa; hardness ≥197HBW
Applications
Mining Industry
Q235B: Primary transport in coal/metal mines for 22-ton side-dump cars, reducing track replacement frequency by 30% vs. lower-spec rails.
55Q: High-abrasion environments (e.g., iron ore pellet transport), extending service life under 25-ton axle loads.
Ports & Logistics
Rubber-tired gantry crane (RTG) tracks in major container terminals.
Heavy-duty forklift routes in logistics hubs, minimizing deformation from frequent 90° turns and start-stop operations.
Metallurgy & Heavy Industry
Steel mill ladle transport tracks in high-temperature zones.
Technical Advantages
Heavy-Duty Load Capacity
Supports 25-ton axle loads (30% higher than 24kg/m rails), covering 95% of industrial Medium-transport and urban transit requirements.
Global Compatibility
Dimensions align with ISO 6501, UIC 54, and JIS E1101, enabling seamless integration with international rail systems via custom fishplates and fasteners.
Material Composition:
Q235B | Mechanical property | Chemical composition | |||||||||
Yield strength | Tensile strength | Elongation | Hardness | C | Si | Mn | S | P | |||
MPa ≥ | kg/mm² | MPa | kg/mm² | min | HB | ≤ | ≤ | ≤ | |||
235 | 24 | 375-460 | 38-47 | 26% |
| 0.12-0.22 | 0.3 | 0.30-0.70 | 0.045 | 0.045 | |
55Q | Mechanical property | Chemical composition(%) | |||||||||
Yield strength | Tensile strength | Elongation | Hardness | C | Si | Mn | S | P | |||
MPa ≥ | kg/mm² ≥ | MPa ≥ | kg/mm² ≥ | min | HBW ≥ |
| ≤ | ≤ | |||
|
| 685 | 69 |
| 197 | 0.50-0.60 | 0.15-0.35 | 0.60-0.90 | 0.040 | 0.040 | |
Why Choose Us?
As a leading Supplier in China, we use localized manufacturing expertise to offer competitive pricing and rapid delivery. Our GB 30kg rail is trusted globally for its consistent quality, safety, and we have more than 15 years experience focused on steel rails.
Explore our full range of steel rails solutions and request a quote today. Partner with us for reliable, high-performance rails that drive efficiency in your operations.
