A55
Product Overview
Elevate your material handling operations with our DIN 536 A55 Heavy-Duty Crane Rail, a state-of-the-art steel solution engineered to excel in the most demanding industrial, port, and rail applications.Fully compliant with German DIN 536 and European EN 13674 standards, this rail delivers robust mechanical properties and exceptional dimensional accuracy, ensuring reliable performance under extreme loads.
Key Features
Optimized Dimensions: With a standardized profile of 65mm (height) × 150mm (base width) × 55mm (head width) × 31mm (web thickness), the rail provides balanced load distribution and stability.
Each 12-meter length weighs 31.8kg/m, designed for seamless integration into existing infrastructure.
Material Excellence:
Manufactured from high-strength 50Mn or 900A alloy steel, the rail boasts a tensile strength of ≥780 MPa, yield strength of ≥680 MPa, and elongation of ≥12%.
This composition significantly enhances resistance to wear, fatigue, and deformation, even in the most challenging heavy-duty environments.
Advanced Manufacturing:
Produced using hot-rolling and precision heat treatment processes, our crane rail maintains a uniform microstructure and minimal dimensional variation.
Adhering to ISO 9001 and CE certifications, our rigorous quality control guarantees consistent excellence.
Applications
Industrial Cranes:
Ideal for overhead cranes, gantry systems, and automated warehouses, ensuring smooth and safe operations.
Port Machinery:
Engineered to withstand the rigorous demands of container handling and marine environments, with exceptional resistance to repetitive stress and corrosion.
Rail system Transportation:
Suitable for specialized industrial tracks where high strength and durability are paramount.
Technical Advantages
Low Maintenance:The high-hardness surface treatment minimizes wear, significantly reducing downtime and lowering operational costs.
Enhanced Corrosion Resistance:Optional protective coatings are available to extend service life in harsh and corrosive environments.
Custom Solutions:Tailored lengths of up to 24 meters and additional accessories, such as fish plates and clips, are available to meet your project-specific requirements.
Material Composition:
| 900A | Mechanical property | Chemical composition(%) | |||||||||
| Yield strength | Tensile strength | Elongation | Hardness | C | Si | Mn | S | P | |||
| MPa | kg/mm² | MPa | kg/mm² | min | HB | ≤ | ≤ | ||||
| 880-1030 | 10% | 0.60-0.80 | 0.10-0.50 | 0.80-1.30 | 0.040 | 0.040 | |||||
| 50Mn | Mechanical Property | Chemical Composition | ||||||||||||
| Yield strength | Tensile strength | Elongation | Hardness | C | Si | Mn | S | P | Cr | Ni | Cu | |||
| MPa | kg/mm² | MPa | kg/mm² | min | HB | ≤ | ≤ | ≤ | ≤ | ≤ | ||||
| ≥390 | ≥40 | ≥645 | ≥66 | 13% | 0.48-0.56 | 0.17-0.37 | 0.70-1.00 | 0.035 | 0.035 | 0.25 | 0.25 | 0.25 | ||
Why Choose Our DIN 536 A55 Crane Rail?
As a leader in crane rail solutions, we integrate German engineering precision with localized manufacturing capabilities to offer competitive pricing and rapid delivery.
Our DIN 536 A55 Heavy-Duty Crane Rails are trusted worldwide for their consistent quality, safety, and adaptability, ensuring that your material handling operations are optimized for efficiency and reliability.
Discover our comprehensive range of crane rails and request a tailored quote. Partner with us for innovative solutions that drive performance and safety in your industrial applications.
