AS68 Rail — AS1085
Product Overview
AS68 rail is an extra-heavy AS1085 rail profile (≈68 kg/m) engineered for the most demanding load cycles — heavy mining haulage, crane support rails and heavy-duty port/terminal applications. Available in standard and head-hardened grades.
Key Features
Dimensions:
Weight: 67.5kg/m
Head Width: 74.6 mm
Rail Height: 185.7 mm
Base Width: 152.4 mm
Web Thickness: 17.5 mm
Length:custom lengths on request
Optional Steel Grades: 900A/1100
Standards: AS 1085.1
Materials, treatments & quality control
Base material: Carbon-manganese rail steels (typical mill grade 900A) for general heavy-duty service.
High-wear option: 1100 / head-hardened variants deliver superior head hardness and extended wear life for abrasive or high-cycle environments.
Documentation: Each batch supplied with MTC showing chemical composition, tensile & yield figures, head hardness and Charpy impact results (on request).
Third-party inspection: SGS / BV / Lloyd’s or equivalent inspection can be coordinated and documented in the contract.
Welding compatibility: Thermit (aluminothermic) and flash-butt welding are supported; welding procedure specifications (WPS) and pre/post-weld guidance provided.
Typical Applications
Heavy-haul mining mainlines and trunk corridors.
Crane and gantry return/support rails in ports, terminals and heavy yards.
Industrial mainlines handling concentrated heavy loads.
Long-life installations where replacement cost and downtime are critical.
FAQs
Q: Which steel grades can you supply for AS68?
A: Standard supply is 900A; head-hardened or 1100 grade rails are available for higher wear resistance. Specify grade and acceptance tests in the PO.
Q:Can AS68 be supplied head-hardened?
A: Yes. Head-hardening is a common option for high-wear applications
Q: How should AS68 be packed for export?
A:Bundled with steel bands, timber spacers and end protection. Specify packing in the order.
Why choose our AS68 rails？
Profile accuracy & CAD support: Supplier CAD/DXF for design integration and clash checks.
Certified quality: MTC for every shipment and optional third-party verification.
Wear-focused options: Head-hardened and higher-grade material choices for abrasion-intensive sites.
Project experience: Hands-on export & project logistics for mining and port projects worldwide.
Turnkey accessory supply: Fishplates, bolts, pads, clips and other accessories delivered to match the rail profile.
