BS Standard Fish Plate

Product Introduction

BS Standard Fish Plate, compliant with BS47-1:1997, are precision-engineered rail joint bars designed to ensure secure and durable connections between railway rails. Manufactured by Glory Rail, these fish plates support seamless rail network operations, catering to both standard and custom rail infrastructure needs.

Value-Added Services

Custom Fabrication: Produce fish plates per client drawings for non-standard rail projects.
Technical Expertise: Engineers assist with rail selection, lifecycle cost optimization, and layout design (e.g., 45° mitre cuts, specialized machining).
End-to-End Solutions: Supply complementary rail components (clips, bolts) and support installation/ maintenance strategies.

Core Specifications

Attribute	Details
Type	BS Standard Railway Fish Plates (Rail Joint Bars)
Material	Q235, 55# (High-strength steel for long service life)
Standard Compliance	BS47-1:1997
Certification	ISO9001:2008 (Quality management system)
Surface Finish	Natural (as-cast) or custom paint/coating (per client requirements)
Hole Configurations	4-hole, 6-hole (matches rail bolt patterns for fast installation)
Customization	Dimensions/designs tailored to BS standards or customer-provided drawings
Origin	China (manufactured with advanced rolling molds for precision)

Key Advantages

Durability: High-strength steel (Q235/55#) ensures long service life, resisting wear from heavy rail traffic.

Ease of Installation: Precise hole alignment and standardized dimensions enable fast, hassle-free rail connections.

Customization: In-house rolling molds and flexible production allow rapid adaptation to unique rail designs or project specs.

Full-Service Support: Paired with bolts, nuts, washers, and technical expertise (e.g., rail cutting, welding, design optimization).

Applications

BS Standard Fish Plates serve as critical connection fasteners for:

Mainline railway networks
Mining rail systems
Crane runway rails
Industrial rail infrastructure

Product Range & Technical Data

Glory Rail offers BS fish plates for diverse rail models (e.g., BS50 “O”, BS60A, BS70A, BS80A, BS100A).

Key specifications for select models:

Rail Model	4-Bolt Length (mm)	6-Bolt Length (mm)	Bolt Hole Diameter (mm)	Weight (4-Hole Pair, kg)	Weight (6-Hole Pair, kg)
BS50 “O”	406.4	609.6	20.64	6.68	10.14
BS60A	406.4	609.6	20.64	9.84	14.76
BS70A	406.4	609.6	23.81	11.10	16.65
BS80A	406.4	609.6	23.81	13.15	19.72
BS100A	457.2	685.8	26.99	19.96	29.94
BS110A	508	914.4	26.99	30.11	54.64
